DEYE three phase high voltage 30KW 40KW 50KW hybrid solar inverter energy storage battery power inverter -Koodsun

DEYE three phase high voltage 30KW 40KW 50KW hybrid solar inverter energy storage battery power inverter



Brand Deye
Product Origin China
Shipping Port Ningbo, Shanghai, Shenzhen
Lead time  7-15days
Time Hybrid
Item No 3 Phase
Lead time 10days
Warranty 10Years



Datasheets



Model
SUN-25K-SG01HP3-EU-BM2
SUN-30K-SG01HP3-EU-BM3
SUN-40K-SG01HP3-EU-BM4
SUN-50K-SG01HP3-EU-BM4
Batery Input Data

Battery Type
Lithium-ion
Battery Voltage Range(V)
150~800V
Max. Charging Current (A
50A+50A
Max. Discharging Current A
50A+50A
External Temperature Sensor
2
Charging Strategy for Li-Ion Battery
Self-adaption to BMS
PV String Input Data

Max. DC Input Power (W)
32500W
39000W
52000W
65000W
Rated PV Input Voltage (V)
1000V
Start-up Voltage (V)
150V
MPPT Voltage Range (V)
200V-850V
Full Load DC Voltage Range (V)
450-850
360-850
360-850
450-850
Rated DC Input Voltage (V)
600
17+17Max. PV I (A)
55A+55A
55A+55A+55A
55A+55A+55A+55A
No. of Strings per MPP Tracker
2
No.of  MPP Trackers
2
3
4
AC Output Data

Rated AC Output Active Power (W)
25000W
30000W
40000W
50000W
Max AC Output Active Power (W)
27500W
33000W
44000W
55000W
AC Output Rated Current (A)
38
45.6
60.8
75.8
Max AC Output Current (A)
50
60
70
83.3
Max. Continuous AC Passthrough (A)
150A
Peak Power (off grid)
1.5 times of rated power, 10 S
Output Frequency and Voltage
50/60Hz;3L/N/PE 220/380Vac,230/400Vac
Grid Type
Three Phase
DC Current Injection
<0.5% In
Efficiency

Max. Efficiency
97.60%
Euro Efficiency
97.00%
MPPT Efficiency
99.90%
Protecton

Integrated
PV Input Lightning Protection,Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection,Output Over Voltage Protection, Surge Protection(DC Type II/AC Type III)
Certficatons and Standards

Grid Regulation
CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 0126-1-1, RD 1699, C10-11
Safety EMC / Standard
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
General Data

Operating Temperature Range (℃)
-40-60℃, >45℃Derating
Cooling
Smart Cooling
Noise (dB)
≤45 dB
Communication with BMS
RS485; CAN
Weight (kg)
60KG
Cabinet Size (WxHxD mm)
560.5W×837H×319D (Excluding Connectors and Brackets)
Protection Degree
IP65
Installation Style
Wall-mounted
Warranty
10 Years



Program







Packing
