GBP48V-50R
GBP48V-100R
GBP48V-200R
Datasheet
Model |
GBP48V-50R |
GBP48V-100R |
GBP48V-200R |
Nominal voltage(V) |
48 |
||
Nominal capacity (AH) |
50 |
100 |
200 |
Working voltage range |
42-56.25 |
||
Recommend charging volt(V) |
52 |
||
Working voltage range |
42-56.25 |
||
Standard charging current(A) |
25 |
50 |
50 |
Max. Constant charging current(A) |
50 |
100 |
100 |
Standard discharging current(A) |
25 |
50 |
50 |
Max. Discharging current(A) |
50 |
100 |
100 |
Temperature(℃) |
-30℃~60℃(Recommend 10℃~35℃) |
||
Allowable humidity range |
0~85% RH |
||
Storage temperature(℃) |
-20℃~65℃(Recommend 10℃~35℃) |
||
Protection |
IP20 |
||
Cooling method |
Natural air cooling |
||
Maximum Dimension(W*D*H)for power wall |
410*640*195 |
||
Net Weight (KG) |
25 |
50 |
90 |
Performance characteristics:
1.Small size and light weight.
2.Maintenance-free.
3.Environmental protection and pollution-free materials, no heavy metals, green and environmental protection.
4.The standard cycle life exceeds 5000 times.
5.Accurately estimate the state of charge of the battery pack, that is, the remaining power of the battery, to ensure that the power of the battery pack is maintained within a reasonable range.
6.Built-in BMS management system with comprehensive protection and monitoring and control functions.
