SOLAR PANEL
Home /SOLAR PANEL /Koodsun Tiger Neo N-Type 72HL4-(V) 565-585 Watt Mono Facial Module 565W 570W 575W 580W 585W Solar Panels
Koodsun Tiger Neo N-Type 72HL4-(V) 565-585 Watt Mono Facial Module 565W 570W 575W 580W 585W Solar Panels -Koodsun
Koodsun Tiger Neo N-Type 72HL4-(V) 565-585 Watt Mono Facial Module 565W 570W 575W 580W 585W Solar Panels -Koodsun

Koodsun Tiger Neo N-Type 72HL4-(V) 565-585 Watt Mono Facial Module 565W 570W 575W 580W 585W Solar Panels

Tiger Neo N-type 72HL4-(V) 565-585 Watt With MONO-FACIAL MODULE 565W 570W 575W 580W 585W Solar Panels

  • Brand:

    Koodsun
  • Product Origin:

    China
  • Color:

    Full Black
  • Shipping Port:

    Ningbo Or Shanghai
  • Number Of Cells:

    144cells
  • Solar Cell:

    N type Mono-crystalline
  • Power Ranger:

    585w
  • Size:

    2278mm×1134mm×35mm
  • Type:

    Monocrystalline
  • Max Power :

    585W
  • Certification:

    IEC/CE/TUV/CSA/CEC/UL
  • Lead Time:

    15days
  • Payment:

    T/T,Credit Card, Paypal, Western Union
  • Warranty:

    25 Years



SMBB Technology: Better light trapping and current collection to improve module power output and reliability

PID Resistance: Excellent Anti-PID performance guarantee via optimized mass-production process and materials control

Durability Against Extreme Environmental Conditions: High salt mist and ammonia resistance

Hot 2.0 Technology: The N-type module with Hot 2.0 technology has better reliability and lower LID/LETID.

Enhanced Mechanical Load: Certified to withstand: wind load (2400 Pascal) and snow load (5400 Pascal)





No. of cells
144 ((6×24)
Module Dimensions
2278×1134×35mm (89.69×44.65×1.38 inch)
Weight
28 kg (61.73 lbs)
Front Glass
3.2mm,Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
Frame
Anodized Aluminium Alloy
Junction Box
IP 68 rated
Output Cables
TUV 1×4.0mm²
(+): 400mm , (-): 200mm or Customized Length
Packaging Configuration
31pcs/pallets, 62pcs/stack, 620pcs/ 40'HQ ContainerCell Type
Maximum Power---Pmax(W)
565Wp
570Wp
575Wp
580Wp
585Wp
Maxinum Power Voltage---Vmp(V)
41.92V
42.07V
42.22V
42.37V
42.52V
Maxinum Power Current---Imp(A)
13.48A
13.55A
13.62A
13.69A
13.76A
Open Circuit Voltage---Voc(V)
50.60V
50.74V
50.88V
51.02V
51.16V
Short Circuit Current---Isc(A)
14.23A
14.31A
14.39A
14.47A
14.55A
Module Efficiency(%)
21.87%
22.07%
22.26%
22.45%
22.65%
Power Output Tolerance(W)
0~+3%
Operating Temperature(ºC)
-40ºC~+85ºC
Maximum system voltage
1000/1500VDC (IEC)
Maximum series fuse rating
25A
