SOLAR INVERTER
Home /SOLAR INVERTER /SRNE Off-Grid Inverter HESP4860S100-H 6KW Hybrid Inverter Support Parallel
SRNE Off-Grid Inverter HESP4860S100-H 6KW Hybrid Inverter Support Parallel -Koodsun

SRNE Off-Grid Inverter HESP4860S100-H 6KW Hybrid Inverter Support Parallel

HESP4850S100-H

HESP4860S100-H

Place of Origin
China



Brand Name
SRNE



Model Number
HESP4860S100-H



Output Voltage
48Vdc



Output Current
230VAC



Output Frequency
50/60(HZ)



Size
556mm*345mm*182mm



Certificate
IEC62109-1, IEC62109-2



Warranty
5 years



Weight
20kg

Datasheet



DATASHEET
HESP4850S100-H
HESP4860S100-H
Battery Voltage
48Vdc
Type of Battery
Lead-acid / Li-ion / User Defined
Rated Power
5000w
6000W
Parallel Capability
Yes, up to 6 units
Output Voltage(Battery Mode)
230VAC ± 5% @ 50/60HZ
Surge Power
10000VA
12000VA
Maximum Photovoltaic Array Power
4000w+4000w
4500w+4500w
Maximum Open-circuit Voltage of Photovoltaic Array
500VDC
Number of independent MPPTs/Number of MPPT Strings per channel
2
Input Rated Voltage
230VAC(single/three phase)
Input frequency range
50/60 HZ(adaptive)
