Battery Type：Lithium Ion
Grid connection：Hybrid grid, Off grid
Model Number：GHR-280/GHR-314.
Brand Name:Koodsun
Place of Origin：Anhui,China
Dimension (L*W*H):530*602*1599/530*602*2187
Weight:116kg/120kg
Communication Port:RS485, CAN
Protection Class:IP20
Cooling:Air cooling
Module Energy (kWh):14.33kwh/16.07kwh
BMS:Smart BMS System
Product Origin :
Anhui,ChinaBrand :
KoodsunMoudle Number :
GHR-280/GHR-314Input Voltage :
51.2VWeight :
116kg/120kgInverter Type :
Hybrid/Off-gridCertificate :
CEWarranty :
10 years
Applicable temperature(°C): -30~60(Recommended 10~35) cooling method: Natural air cooling Life cycles: 6000+times at 80% DOD Storage temperature(°C): -20~65(Recommended10~35) Protection level: IP20 Standard charging current(A): 50 Operating voltage range: 42-54.75 Nominal voltage(V): 51.2
Brand Name: DEYE Model Number: BOS-G Pro Certification: CE/IEC62619 /VDE2510-50/ UL1973 /UL9540A/UN38.3 Weight: 290kg The charging ratio: 100% The discharge rate: 90% Battery type: Lifepo4 Battery Cell Warranty: 10 Years Installation Location: Rack Mounting IP Rating of Enclosure: IP20
Grid Type: Three phase Number of parallel: 10 Energy Configuration (kWh): 122.8 AC Output Rated Current (A): 75.8 Battery Chemistry: LiFePO4 IP Rating of Enclosure: IP55 Installation Style: Floor-Mounted Display: LCD Inverter Communication: CAN,RS485,WIFI,ETH Battery Module Certification: UN38.3,IEC62619,IEC61000
Battery Type：LiFePO4 Nominal Voltage (V)：51.2 Nominal Capacity(Ah)：280 Discharge Voltage (V)：44.0V-58.4V Dimension (mm)：435*234*800 Weight (kg)：140 Warranty：10 years Communicaiton：CAN/RS-485
Cell Chemistry: LiFePO4 Module Energy ( kwh ): 7.68 Module Nominal Voltage (V ): 38.4 Module Capacity (Ah): 200 Communication Port: CAN2.0 Humidity: 5%~85%RH Storage Temperature ( °C ): 0~35 Recommend Depth of Discharge: 90% Warranty: 10 years Certification: CE/IEC 62619/IEC62040/UN38.3/VDE-2510
Battery Type：LiFePO4 Nominal Voltage (V)：51.2 Nominal Capacity(Ah)：280 Discharge Voltage (V)：44.0V-58.4V Dimension (mm)：435*234*800 Weight (kg)：140 Warranty：10 years Communicaiton：CAN/RS-485
Battery Type：LiFePO4 Nominal Voltage (V)：51.2 Nominal Capacity(Ah)：314 Discharge Voltage (V)：44.0V-58.4V Dimension (mm)：801*533*233 Weight (kg)：160 Warranty：10 years Communicaiton：CAN/RS-485
Applicable temperature(°C): -30~60(Recommended 10~35) cooling method: Natural air cooling Life cycles: 6000+times at 80% DOD Storage temperature(°C): -20~65(Recommended10~35) Protection level: IP20 Standard charging current(A): 50 Operating voltage range: 42-54.75 Nominal voltage(V): 51.2
