Home /SOLAR INVERTER /Growatt Three Phase Inverter Hybrid Solar Power System Residential Storage Inverter SPH 10000TL3 BH-UP
Growatt Three Phase Inverter Hybrid Solar Power System Residential Storage Inverter SPH 10000TL3 BH-UP -Koodsun

Growatt Three Phase Inverter Hybrid Solar Power System Residential Storage Inverter SPH 10000TL3 BH-UP

SPH 4000TL3 BH-UP

SPH 5000TL3 BH-UP

SPH 6000TL3 BH-UP

SPH 7000TL3 BH-UP



SPH 8000TL3 BH-UP

SPH 10000TL3 BH-UP

Place of Origin
China



Brand Name
Growatt



Model Number
SPH 10000TL3 BH-UP



Input Voltage
100~550V



Output Voltage
230V/400V



Output Current
7.6A-15.2A



Output Frequency
50/60(HZ)



Size
505*453*198mm



Certificate
CE / TUV



Warranty
5/10 years



Weight
30kg



MPP voltage range
120V-1000V/600V



Adjustable power factor
0.8leading...0.8lagging



THDi
<3%



AC grid connection type
3W+N+PE



Type of battery
<div class="right" style="border: 1px solid #dddddd; --tw-border-spacing-x: 0; --tw-border-spacing-y: 0; --tw-translate-x: 0; --tw-translate-y: 0; --tw-rotate: 0; --tw-skew-x: 0; --tw-skew-y: 0; --tw-scale-x: 1; --tw-scale-y: 1; --tw-scroll-snap-strictness: proximity; --tw-ring-offset-width: 0px; --tw-ring-offset-color: #fff; --tw-ring-color: rgba(59,130,246,.5); --tw-ring-offset-shadow: 0 0 #0000; --tw-ring-shadow: 0 0 #0000; --tw-shadow: 0 0 #0000; --tw-shadow-colored: 0 0 #0000; margin: 0px; padding: 12px; font-style: inherit; font-variant: inherit; font-stretch: inherit; font-size: 16px; line-height: 22px; font-family: inherit; font-optical-sizing: inherit; font-kerning: inherit; font-feature-settings: inherit; font-variation-settings: inherit; vertical-align:
Inquire Now

Datasheets

Datasheet
SPH 4000TL3 BH-UP
SPH 5000TL3 BH-UP
SPH 6000TL3 BH-UP
SPH 7000TL3 BH-UP
SPH 8000TL3 BH-UP
SPH 10000TL3 BH-UP
Input data(PV)
Max. recommended PV power
(for module STC)
6000W
7500W
9000W
10500W
12000W
15000W
Max. DC voltage
1000
Start voltage
120V
MPP voltage range
120V-1000V/600V
No. of MPP trackers
2
No. of PV strings per MPP tracker
1
Max. input current per MPP tracker
13.5A
Max. short-circuit current per MPP tracker
16.9A
Output data(AC)
AC nominal power
4000W
5000W
6000W
7000W
8000W
10000W
Max. AC apparent power
4000VA
5000VA
6000VA
7000VA
8000VA
10000VA
Nominal AC voltage (range*)
230V/400V (310~476V)
AC grid frequency (range)
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
Max. output current
6.1A
7.6A
9.1A
10.6A
12.1A
15.2A
Adjustable power factor
0.8leading…0.8lagging
THDi
<3%
AC grid connection type
3W+N+PE
Battery data (DC)
Battery voltage range
100~550V
Max charging and discharging current
25A
Continuous charging and discharging power
4000W
5000W
6000W
7000W
8000W
10000W
Type of battery
lithium/lead-acid
Backup power(AC)
Max. AC output power
4000W
5000W
6000W
7000W
8000W
10000W
Max. AC apparent power
4000VA
5000VA
6000VA
7000VA
8000VA
10000VA
Max. output current
6.1A
7.6A
9.1A
10.6A
12.1A
15.2A
Nominal AC output voltage
230V/400V
Nominal AC output frequency
50/60HZ
THDv
<3%
Switch time
<10ms
Efficiency
MAX. efficiency
97.6%
97.8%
98.0%
98.2%
98.2%
98.2%
European efficiency
97.0%
97.2%
97.3%
97.4%
97.4%
97.4%
Euro battery discharge efficiency
97.4%
MPPT efficiency
99.9%
Protection devices
DC switch
Yes
DC reverse polarity protection
Yes
AC/DC surge protection
Type II
Battery reverse protection
Yes
AC short-circuit protection
Yes
Ground fault monitoring
Yes
Grid monitoring
Yes
Anti-islanding protection
Yes
Residual-current monitoring unit
Yes
Insulation resistance monitoring
Yes
General data
Dimensions (W / H / D)
505/453/198mm
Weight
30kg
Operating temperature range
–25 °C ... +60 °C
Nighttime power consumption
<13W
Topology
Transformerless
Cooling
Natural
Protection degree
IP65
Relative humidity
0~100%
Altitude
3000m
DC connection
H4 / MC4 (Optional )
AC connection
Connector
Display
LCD+LED
Interfaces: RS485/CAN/USB
Yes
Monitor : RF/WIFI/GPRS
Optiona
Warranty: 5 years / 10 years
Yes / Optional
CE, IEC62109, IEC 62040, VDE-AR-N 4105, VDE 0126, UTE C 15-712, C10/C11，EN50549, CEI 0-21, CEI 0-16, IEC62116, IEC61727, AS/NZS
4777 , G98, TOR Erzeuger



packing
