Megarevo split phase three phase hybrid inverter 6kw 8kw 10kw 12kw solar inverter for home energy storage systems

Place of Origin

Jiangsu, China

Brand Name

MEGAREVO

Model Number

R6KH1NA

Input Voltage

500V

Output Voltage

240/211~264V

Output Current

27.5~50A

Output Frequency

50/60(HZ)

Size

560* 220* 680mm

Certificate

UL1741SA all options

Warranty

5 Years

Weight

34KG

MPPT Voltage Range

125~500V

MPP Tracker/Strings

4/1

Battery Voltage Range

85~400V

Battery Type

Lithium /Lead-acid

Inquiry now

Datasheets

Technical specification	R6KH1NA	R8KH1NA	R10KH1NA	R12KH1NA
Input (PV)
Max. power(kW)	7.8	10.4	13	15.6
Max. DC voltage(V)	500
MPPT voltage range(V)	125~500
Max.Input current of single MPPT(A)	12
MPPT tracker/strings	4/1
AC output
Rated output power(kVA)	6	8	10	12
Max. apparent Power (kVA)	6.6	8.8	11	12
Max. output current(A)	27.5	36.7	45.8	50
Grid voltage/range(V)	240/211~264
Frequency (Hz)	50 /60
PF	0.8lagging-0.8leading
THDi	<3%
AC output topology	Split phase、single phase
Battery
Battery voltage range(V)	85~400
Max. charging voltage(V)	400
Full battery voltage(V)	85	110	140	160
Max. charge/discharge current(A)	80/80
Battery type	Lithium /Lead-acid
Communication interface	CAN,RS485
EPS output
Rated power (kVA)	6	8	10	12
Rated output voltage(V)	220-240 /110-120
Rated frequency(Hz)	50/60
Automatic switching time (ms)	<20
THDu	＜2%
Overload capacity	110%,30S/120%,10S/150%,0.02S
General data
DC Max. efficiency	≥98.2%
CEC efficiency	≥97.2%
Ingress protection	IP65/NEMA 3R
Noise emission(dB)	＜25	＜25	＜29	＜29
Operation temperature(℃)	-25～60
Cooling	Natural
Relative humidity	0 ~95%（non-condensing）
Operation altitude (m)	2,000 (>2,000 Derating)
Weight(kg)	34
Dimensions W * D * H (mm)	560* 220* 680
Self-consumption(W)	＜20
Display and communication
Display	LCD
Interface:RS485/Wifi/4G/ CAN	Yes/ Opt/ Opt/ Yes
Safety standard	UL1741SA all options, UL1699B, CSA 22.2
EMC	FCC Part 15, Class B
On-grid	IEEE 1547, Rule 21, Cpuc Rule 21, SRD V2.0 UL1741SA, UL1741SB
On-grid	IEEE1547, CPUC Rule21, SRD V2.0, UL1741 SA, UL1741 SB
DC ARC-Fault	UL1699B
