Datasheet
Model
|
100KTLX2-G4
|
Input (DC)
|
|
Max. input voltage
|
1100V
|
Rated input voltage
|
625V
|
Start-up voltage
|
200V
|
MPPT operating voltage range
|
180V~1000V
|
Number of MPP trackers
|
10
|
Number of DC inputs
|
20
|
May input MPPT current
|
10*40A
|
Max. input short circuit current
|
10*50A
|
Output (AC)
|
|
Rated output power
|
100kW
|
Max. apparent power
|
100kVA@45℃/90kVA@50℃
|
Max. output current
|
152A@380V/145A@400V/139.2A@415V
|
Pated output yoltage
|
3/N/PE,380V/400V/415V
|
Output voltage range
|
310-480V
|
Rated output frequency
|
50/60 Hz
|
Output frequency range
|
45-55Hz/55~65Hz
|
Active power adjustable range
|
0~100%
|
THDi
|
<1%(@100%P)
|
Power factor
|
1(+/-0.8 adjustable)
|
Efficiency
|
|
Max. efficiency
|
98.6%
|
European efficiency
|
98.3%
|
General Data
|
|
Ambient temperature range
|
30℃~+60℃
|
Topology
|
Transformerless
|
Degree of protection
|
IP66
|
Allowable relative humidity range
|
0-100%
|
Max.operating altitude
|
4000m (>3000m derating)
|
Cooling
|
Smart air cooling
|
Dimension (W×H×D)
|
970×695×325mm
|
Weight
|
75kg
|
Display
|
LCD &Bluetooth +APP
|
Communication
|
RS485/WiFi
|
Standard
|
EN/EC 62109-12,EN/EC 61000-6-2-4,EC 61000-3-4-5,EN 50530,EN 50549,1EC62116,IEC 61727,EC 61683, EC 60068-2-1/2/14/30,VDE V
0126-1-1,UTE C15-712-1,VDE-AR-N 4105/4110,CE 0-21/16, NTS 631, UNE 217001,UNE 217002, G99,C10/11 |
Advantage
Max. efficiency up to 98.6%
IP66 & C5 design for outdoor
Maximum 10 MPPTs, 40A per MPPT
Type I + II SPD for DC
I-V curve scanning function
Battery connector for ESS, DC coupled
Project
