DEYE High Voltage 15KW 20KW Storage Three Phase Hybrid Solar Inverters 3 Phase -Koodsun
DEYE High Voltage 15KW 20KW Storage Three Phase Hybrid Solar Inverters 3 Phase -Koodsun
DEYE High Voltage 15KW 20KW Storage Three Phase Hybrid Solar Inverters 3 Phase -Koodsun

DEYE High Voltage 15KW 20KW Storage Three Phase Hybrid Solar Inverters 3 Phase

  • Product Origin:

    China
  • Shipping Port:

    Ningbo, Shanghai, Shenzhen
  • Type:

    Deye Hybrid Solar Inverter
  • Output Voltage :

    360-440V 60hz
  • Item No:

    3Phase
  • Certification:

    CE, TUV, IEC, UL, VDE,,,,Etc
  • Lead Time:

    10-20days
  • Warranty:

    10 Years

DEYE High Voltage 15KW 20KW Storage Three Phase Hybrid Solar Inverters 3 Phase

Specifications of DEYE 3phase 30KW 50KW Hybrid Inverter DC/AC



Model
SUN-15K-SG01
HP3-EU-AM2

SUN-20K-SG01
HP3-EU-AM2

Battery
Battery Type lithium ion
Battery Voltage Range 160-700V
MAX Charging Current 37A 37A
MAX Discharger Current 37A 37A
Number of Battery Input 1 1
External Temperature Sensor YES YES
Charging strategy for Lithium battery Self adaptation to BMS

PV Input Data
MAX PV Input Power 19500W 26000W
MAX PV Input Voltage 1000VDC
MPPT Voltage Range 150-850VDC
PV Input Current 26A+20A 26A+26A
NO. of MPPT Trackers 2 2
No. of PV Strings per MPPT 2+1 2+2

AC Output Data
Rated AC Output Power and UPS power 15000W 20000W
MAX AC Output Power 16500W 22000W
Peak Power of OFF GRID 1.5TIMES of Rated Power, 10S.
AC Output Rated Current 22.8/22.8A 30.4/30.4A
Max. Continuous AC Passthrough (A) 80A 80A
Output Frequency and Voltage 50/60Hz; 230/400Vac (Three phase) 50/60Hz; 230/400Vac (Three phase)
Current Harmonic Distortion THD<3% (Linear load<1.5%) THD<3% (Linear load<1.5%)

Efficiency
MAX Efficiency 97.6% 97.6%
MPPT Efficiency 99.9% 99.9%

Protection
PV Input Lightning Protection Integrated Integrated
Anti-islanding Protection Integrated Integrated
PV String Input Reverse Polarity Protection Integrated Integrated
Output Over Current Protection Integrated Integrated
Output Over Voltage Protection Integrated Integrated
Surge protection DC Type II / AC Type II DC Type II / AC Type II

Certiffcations and Standards
Grid Regulation IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1 IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC/Standard IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12 IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12



As the official authorized dealer of DEYE, we, KOODSUN, can sell all products of DEYE.

Including but not limited to various types of inverters, lithium batteries, micro-inverters and other products.

We provide comprehensive after-sales and technical support for all products.

For long-term and powerful customers, we will contact DEYE engineers to go to the customer's country for technical installation guidance and product training.

All products are in stock.

We also offer Complete solar systems solution, which include solar panel, solar inverter, storage battery,,,,etc.

DDP service around the world.
